Printer
 Specifications

  Print Method

  Direct Thermal

  Print Resolution

  203 dpi

  Print Speed

  4~8 inch/s (101-203mm/s)

  Print Width

  Max. 104mm (4.09")

  Print Length

  Max. 2286mm (90")

  Dot Density

  203dots/inch (8dots/mm)

  Dot Size

  0.125x0.125mm (1mm=8dots)

  Print Head

  50KM

  Interface

  USB+RS232

 Media
 Characteristics

  Media Roll OD

  130mm (5")

  Media Type

  Thermal paper, Thermal label, Adhesive thermal paper

  Media Rolling Up  Method

  Printing side outward rolling

  Media Width

  Max.120mm (4.72")   Min.40mm (1.56")

  Media Thickness

  Max. 0.254mm (10mil)   Min. 0.06mm (2.36mil)

  Media Roll Core Size

  25.4mm~38mm (1"~1.5")

  Media Gap

  Min. 2 mm (0.09")

  Label Length

  10~2286mm (0.39"~90")

 BarCode/Fonts/
 Graphics  Symbologies

  Enlargement&Rotation

  1 ~10 times enlargement in both directions;    0°、90°、270°、360°rotation

  Character Size

  Font 0 ~ font 8

  1D Barcode

  Code39, Code93, Code128 subsets A, B, C, Codabar,    Interleaved 2 of 5, EAN-  13, EAN-14, EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on, MSI,  PLESSEY, POSTNET, china POS, ITF14

  2D Barcode

  QR code

  Graphics Processing

  Support BMP/PCX/BAS files

  Editing Software

  Nicelabel  SE

 Operating
 Characteristics

  Power supply

  Input: AC 110V/240V     Output: DC24V/2.5A, 60W

  Operation Condition

  Temperature: 5~45℃(41~104℉),  Humidity:    25~85%RH

  Storage Condition

  Temperature: -10~50℃(-10~140℉), Humidity:  10%~90%RH

 Physical
 Characteristics

  Printer Dimensions

  285*210*180mm (WxDxH)

  Printer Weight

  Approx. 2.1KG

 Accessories

  External Media      Holder

  Optional
